Features:
- Supports upto 4,00,000 RFID card/mobile credential, 400,000 fingerprint, 100,000 facial and 10000 palm authentication in one single controller.
- Supports BACnet, Modbus, OPC, and various reader protocols
- Power over Ethernet (PoE 802.3at/af) and flexible voltage inputs (9-24V)
- Unlimited threat levels for immediate lockdown adjustments
- Port failover redundancy for advanced access control
- 100,000 access levels with a 300,000-event transaction buffer
- Supervised and programmable inputs that can detect upto 5% ohms in circuit
- Enhanced tamper-proof and copy-proof functions with EAL6+ crypto chips
- Does IP/MAC address filtering
- Offers three different models for a variety of doors
- AES encryption for communication protection between controller and edge devices
Technical Specs:
- PoE (802.3at/af) is capable of powering the device or a 9-24VDC power supply that does not exceed 550mA (reader current excluded)
- Communicates through a primary PoE interface and a secondary BLE 5.2 interface
- Communication between the controller and server, as well as between controllers, is protected by 256-bit AES encryption
- Two Ethernet ports are 100Base-TX — Port 1; the second one also has port failover capability
- Device has three ports – Port 1 is Armatura RS-485/OSDP V2.2, Port 2 is also Armatura RS-485/OSDP V2.2, and Port 3 is Armatura RS-485/OSDP V2.2 with port redundancy capability on Ports 2 and 3
- Total of two TCP/IP ports, three RS-485 ports, and two Wiegand ports
- Onboard monitor uses a 320×240 resolution TFT display that measures about 2.4 inches diagonally; it’s used for status and configuration purposes
- Can support up to one hundred thousand access levels
- RS-485 protocol used here comes with AES-128 as well as OSDP Secure Channel security features
- 30 ounces or approximately 830 grams weight
