Features:
- Supports up to 800,000 RFID card credentials (1:1) and 400,000 mobile credentials (1:N)
- Handles 100,000 fingerprints (1:1), 100,000 facial recognitions (1:1), and 5,000 palm authentications (1:N)
- EAL6+ embedded crypto chip for tamper-proofing and copy protection
- IP/MAC address filtering function and AES encryption for secure communication
- Supervised inputs for circuit anomaly detection (5% Ohms)
- Dedicated microchips for control panel tamper, fire alarm, and REX input
- Supports three models for a variety of applications
- Four onboard access points supporting up to eight readers
- Supports up to 24 AHEB series IO expansion boards (384 inputs/385 outputs)
Technical Specs:
- Power over Ethernet (PoE 802.3at/af) and flexible voltage inputs (9-24V DC)
- Compatible with BACnet, Modbus, OPC, and various reader protocols
- Three RS-485 ports and four Wiegand ports for redundancy and failover
- Unlimited threat levels for immediate lockdown adjustments
- Onboard web server for easy configuration management
- Transaction buffer of up to 300,000 events and 100,000 access levels
- Compact design with PoE support for easy installation
- Secure AES encryption between controller, server, and edge devices
- User-friendly dashboard for configuration management
- Supports instant lockdown adjustment
- Suitable for high-security access control requirements
